accurate external diameter grinding machine (standard type)
|
Model
|
ZJ-W010
|
Project
|
Specification
|
Project
|
Specification
|
Can grasp the working diameter
|
φ 0.5- φ 25mm
|
main shaft speed
|
0-12000rpm
|
Give into the way
|
Before and after
|
40mm
|
Main shaft motor
|
3/4HP,3φ
|
Left right
|
70mm
|
Mechanical size
|
Mainframe , minicomputer
|
Rotational speed of beginning work
|
180rpm
|
Mechanical weight (invite)
|
180kgs
|
job head rotates angle
|
± is 5 degrees
|
Processing range (external diameter )
|
φ0.5-φ25mm
|
|
|
Suitable target of machinery
|
Drift , thimble
|
Spray nozzle,carburetor
|
Careful of the axle,valve a little
|
Hollow , rivet drift
|
Pen mould,screw mould,knitting machine components
|
The small external diameter of relevant spare parts is ground
|
|
Standard enclosure:
Emery wheel spanner (one) Spanner 10-12 (one) Emery wheel (one)
Repair one one hundred sheets of seats (one) Manual (one) free The gyro wheel (1 set)
Six mao spanner inside (1 set)
pecial enclosure:
Optics chi
Wash by water to fitSeriously promise: The platform of our company machine guarantees to exchange if returned as unsuitable in three months like being defective in quality.
